LEDs
|
|
|
|
| Type
|
Description
|
Size
|
Qty
|
Price
|
|
| 3mm red
|
3mm Red Led 80mcd
|
3mm
|
1
|
$0.20
|
| 3mm yellow
|
3mm Yellow Led 35mcd
|
3mm
|
1
|
$0.20
|
| 3mm green
|
3mm Green Led 50mcd
|
3mm
|
1
|
$0.20
|
| SB5R
|
Red LED 1000mcd Jap
|
5mm
|
1
|
$1.00
|
|
| SB5G
|
Green LED 1500mcd Jap
|
5mm
|
1
|
$1.80
|
|
| SB5B
|
Blue LED 1200mcd Jap
|
5mm
|
1
|
$1.30
|
|
| SBW5SAN
|
White Led 10cd China
|
5mm
|
1
|
$1.00
|
|
| SB5W500
|
White LED 27cd Jap
|
5mm
|
1
|
$1.20
|
|
| SB5W510
|
White Led 7Cd Jap
|
5mm
|
1
|
$1.20
|
|
| 5RFL
|
5mm Red Flashing Led h/b
|
5mm
|
1
|
$0.80
|
| 5GL
|
5mm Green Led
|
5mm
|
1
|
$0.25
|
| 5YL
|
5mm Yellow Led
|
5mm
|
1
|
$0.25
|
| 5OL
|
5mm Orange Led
|
5mm
|
1
|
$0.25
|
| 5HL
|
5mm Led Housing
|
5mm
|
1
|
$0.20
|
| 10RL
|
10mm Red Led
|
10mm
|
1
|
$0.40
|
| 10RFL
|
10mm Red Flashing Led
|
10mm
|
1
|
$1.00
|
| 10GL
|
10mm Green Led 6cd
|
10mm
|
1
|
$1.40
|
| 10YL
|
10mm Yellow Led 3cd
|
10mm
|
1
|
$0.40
|
| 10BL
|
10mm Blue Led 5cd
|
10mm
|
1
|
$1.40
|
| 10LH
|
10mm Led Housing Black
|
10mm
|
1
|
$0.50
|
|
|
|
|
|
|
SMD LEDs
|
|
|
|
|
|
| SMD LEDs - As used in Nokia phone conversions. 5210-6210-3310-3320 etc
|
| Type
|
Description
|
Size
|
Qty
|
Price
|
|
| Superbright
|
SMD Red LED
|
603 (tiny)
|
1
|
$1.00
|
|
| Superbright
|
SMD Orange LED
|
603 (tiny)
|
1
|
$1.00
|
|
| Superbright
|
SMD Yellow LED
|
603 (tiny)
|
1
|
$1.00
|
|
| Superbright
|
SMD Blue LED
|
603 (tiny)
|
1
|
$2.00
|
|
| Superbright
|
SMD White LED
|
603 (tiny)
|
1
|
$2.00
|
|
|
|
|
|
|
| SMD LEDs - As used in older phones or lighting
|
| Type
|
Description
|
Size
|
Qty
|
Price
|
|
| Superbright
|
Red
|
1206
|
1
|
$0.50
|
|
| Superbright
|
Orange
|
1206
|
1
|
$0.50
|
|
| Superbright
|
Yellow
|
1206
|
1
|
$0.50
|
|
| Superbright
|
Blue
|
1206
|
1
|
$2.50
|
|
| Superbright
|
White
|
1206
|
1
|
$2.50
|
|
|
|
|
|
|
| These LEDs are Superbright, 50 - 110 mcd @120 Deg
|
|
| Superbright
|
Red
|
1210 / PLCC-2
|
1
|
$0.28
|
|
| Superbright
|
Yellow
|
1210 / PLCC-2
|
1
|
$0.28
|
|
| Superbright
|
Green
|
1210 / PLCC-2
|
1
|
$0.35
|
|
| Superbright
|
White
|
1210 / PLCC-2
|
1
|
$0.35
|
|
| Superbright
|
Blue
|
1210 / PLCC-2
|
1
|
$0.35
|
|
|
|
|
|
|
These LEDs are Ultrabright, 800 - 1200 mcd @ 120 deg, all colors,
and 1500 - 3500 mcd @ 60 degrees, red and yellow stocked only.
Note: equivalent to 6000 - 15000mcd @ 10 Deg
Can be driven to 50ma (max)
They have 4 pins on base and need pcb layout pads for heatsinking
|
| Ultrabright
|
Red 2000-3000mcd
|
1210 / PLCC-4
|
1
|
$0.60
|
|
| Ultrabright
|
Yellow 2000-3000mcd
|
1210 / PLCC-4
|
1
|
$0.60
|
|
| Ultrabright
|
Green 1000-1500mcd
|
1210 / PLCC-4
|
1
|
$1.20
|
|
| Superbright
|
White 800-1200mcd
|
1210 / PLCC-4
|
1
|
$1.20
|
|
| Superbright
|
Blue 500-650mcd
|
1210 / PLCC-4
|
1
|
$1.20
|
|
| These are not domed but 120 Degree LEDs
|
|
|
Red & yellow are available in both types;
Domed 60 degrees and non domed 120 degrees
Please quote which type
|
|
|
|
|
|
|
|
|
|
|
|
|
| IC'S for driving Leds
|
|
|
| On Semi
|
NUD4001 IC
|
8 Pin SOT
|
10ma - 500ma (Max)
|
@ 1.85 ea
|
| ST Micro
|
STCS1
|
8 Pin SOT
|
10ma - 1.2A (Max)
|
@ 3.50 ea
|
| Please view Manufacturers Specs before purchase and also de-rate by 40% for reliable use
|
| These IC's are Linear Led Drivers and require Heat sinking to PCB
|
|
|
|
|
|
|
|
|
|
|
|
| 1 Watt SMD LEDs |
Please note
that these LEDs are not toys,
can
damage eyes if stared directly at,
and
they require Min 25mm Square pad
size around them
for heatsinking.
|
|
Red
@ 40 deg Dome Lens
Approx
30 - 35 Lumens Brightness
run
2.5V at 350ma Max
Led
size is 7mm x 6mm
$4.80 ea
|
|
|
Yellow
@ 40 deg Dome Lens
Approx
30 - 35 Lumens Brightness
run
2.5V at 350ma Max
Led
size is 7mm x 6mm
$4.80 ea
|
|
|
Blue
@ 40 deg Dome Lens
Approx 15 - 20 Lumens Brightness
run
2.5V at 350ma Max
Led
size is 7mm x 6mm
$6.50 ea Arriving soon...
|
|
|
Green
@ 40 deg Dome Lens
Approx 20 - 25 Lumens Brightness
run
2.5V at 350ma Max
Led
size is 7mm x 6mm
$6.50 ea Arriving soon...
|
|
|
White
@ 40 deg Dome Lens
Approx 28 - 32 Lumens Brightness
run
2.5V at 350ma Max
Led
size is 7mm x 6mm
$6.50 ea
|
|
|
|
|
|
|
|
|
|
|
|
|
Cover Chart for LED/ Incandescent/ Halogen/ Fluorescent, for reference only:
|
| Products |
Power LM/W |
Life / Hours |
| Incandescent < 25W |
8 |
3000 |
| Incandescent > 50W |
15 |
1000 |
| Halogen |
24 - 30 |
2000 |
| Fluorescent |
80 |
20000 |
| LED Today |
60-80 |
30000 |
| LED Future |
100 - 350 + |
100000 |
|
